8 / EN

3-in-1 Cordless Vacuum Cleaner / User Manual

Values supplied with the instrument or accompanying documentation are laboratory readings per rele-

vant standards. These values may differ depending on operation and ambient conditions.

2.1 Controls and components

1. Battery pack release button

2. Battery pack assembly

3. Self-cleaning button

4. Mute button

5. Dust cup assembly

6. Release button for the bottom cover of the

dust cup

7. Metal tube

8. Sewage tank

9. Floor brush release button

10. Handle of clean water tank

11. Water injection mouth of clean water tank

12. Water-spraying mouth

13. Sewage tank release button

14. Handheld release button

15. Handheld dust cup release button

16. Display screen

17. Gear button

18. ON/OFF button

19. Water-spraying button

2.2 Accessories

1. Hanger assembly for accessories

2. Charging holder

3. Flat suction

4. Pet brush

5. Carpet brush

6. Metal tube

7. Sofa suction

8. Power cable

9. Multi-function clean brush

2.3 Technical data

Nominal input power 400 W

Input 220-240V 50-60Hz

Waterproof IPX4 for EB123

Output 25.8Vdc 1.0A

Charging time 4-5.5Hours

Working time under

maximum power

40 minutes

Working time under

minimum power

60 minutes

Handheld turbo timing 32 min

Working time at max

power

1) handheld max

mode: 38 min

2) Dry Brush Side max

mode: 26 min

3) Wet&Dry: 16 mins

Working time at min

power

1) handheld min mode:

60 min

2) dry brush side min

mode: 50 min

3) Wet&Dry: 25 mins

2.4 Product Specifications

This device has three functions: Vacuuming; Mop

and Self-cleaning.

Clean Water Tank Capacity : 650 ml

Dirty Water Tank Capacity : 400 ml

• WARNING! Only use water below 25C°. Do

not use boiling water. Don’t use high foaming

detergent.

2.4.1 Floor Surface Cleaning

The product is equipped with a clean water tank,

dirty water tank, floor cleaning roller brush, motors

and other functional modules. Water is pumped

into the floor-cleaning roller brush, and the

floor-cleaning motor makes it spin at high speed

to clean surfaces. After cleaning the floor, the dirty

water is sucked by the suction motor and drawn

back into the dirty water tank. During the floor

cleaning process, the level of spraying water on the

cleaning roller brush can be adjusted or cancelled.

2 Overview
