10 / EN

3-in-1 Cordless Vacuum Cleaner / User Manual

3 Installation

3.3 Install the charger holder assembly

Removal:

First, place the stand. Then fix

the apparatus compartment on

top evenly with the tabs of the

stand. Attach the charging ap-

paratus on top

Press the charging head as-

sembly, the hanger assembly for

accessories along the position

shown in the figures toward the

charging holder. After hearing

the “click” sound, the hook is

clipped into the corresponding

hole position, and the installa-

tion is successful.

3.4 Roller brush cover removal and mounting

Spline

- To remove the roller brush assembly, it is necessary to remove the

water tank assembly.

- Then you can use a hand to press the floor brush, the other hand to

rotate the end cover of the roller brush upward, and remove the roller

brush outwards; When installing the roller brush assembly, first align

the other end of the roller brush with the spline, rotate it to the end,

then push the roller brush inward, rotate the roller brush end cover

downward and install it in place.

- Install the clean water tank

C

Do not use on carpet when the product is in mop mode, if it is to be used on carpet, it should

be used with a dry vacuum cleaner nozzle.
