Split type air conditioner / User Manual
39 / EN
Drain hose must be on bottom
Make sure that the drain hose is at the bottom of
the bundle. Putting the drain hose at the top of
the bundle can cause the drain pan to overflow,
which can lead to fire or water damage.
Do not intertwine signal cable with other
wires
While bundling these items together, do not
intertwine or cross the signal cable with any
other wiring.
2. Using adhesive vinyl tape, attach the drain
hose to the underside of the refrigerant pipes.
3. Using insulation tape, wrap the signal wire,
refrigerant pipes, and drain hose tightly
together. Double-check that all items are
bundled.
Do not wrap ends of piping
When wrapping the bundle, keep the ends of
the piping unwrapped. You need to access them
to test for leaks at the end of the installation
process (refer to Electrical checks and leak
checks section of this manual).
Step 8: Mount indoor unit
If you installed new connective piping to the
outdoor unit,do the following:
1. If you have already passed the refrigerant
piping through the hole in the wall, proceed to
Step 4.
2. Otherwise, double-check that the ends of the
refrigerant pipes are sealed to prevent dirt or
foreign materials from entering the pipes.
3. Slowly pass the wrapped bundle of refrigerant
pipes, drain hose, and signal wire through the
hole in the wall.
4. Hook the top of the indoor unit on the upper
hook of the mounting plate.
5. Check that unit is hooked firmly on mounting
by applying slight pressure to the left and
right-hand sides of the unit. The unit should
not jiggle or shift.
6. Using even pressure, push down on the
bottom half of the unit. Keep pushing down
until the unit snaps onto the hooks along the
bottom of the mounting plate.
7. Again, check that the unit is firmly mounted
by applying slight pressure to the left and the
right-hand sides of the unit.
8 Indoor unit installation
