Split type air conditioner / User Manual
29 / EN
Name Shape
Quantity (PC)
Connecting pipe
assembly
Liquid side
Ø6.35 (1/4 in)
Parts you must purchase
separately. Consult the
dealer about the proper
pipe size of the unit you
purchased.
Ø9.52 (3/8in)
Gas side
Ø9.52 (3/8in)
Ø12.7 (1/2in)
Ø16 (5/8in)
Ø19 (3/4in)
Magnetic ring and belt
(if supplied ,please refer
to the wiring diagram
to install it on the
connective cable.)
1 2 3
Pass the belt through the
hole of the Magnetic ring
to fix it on the cable
Varies by model
