26 / 76 EN
Local air conditioner / User Manuel
5.1 Installation
A
Warning: before using the mobile air conditioning, keep it
upright for at least two hours.
The air conditioning can be easily moved in the room. In the moving process, ensure that the air
conditioning is in the upright position and the air conditioning should be placed on a flat surface. Do
not install and use the air conditioning in the bathroom or other humid environments.
1. Install the heat pipe assembly (as shown in Fig. 1)
Push
Fig. 1
1) Take out the outer connector assembly and the exhaust pipe assembly, and remove the plastic
bags;
2) Insert the heat pipe assembly (the end of the exhaust joint) into the back panel vent slot (push to
the left) and complete the assembly (as shown in fig. 1).
2. Installation of window sealing plate components
1) Half open the window, and mount the window sealing plate assembly to the window (as shown in
Fig. 2 and Fig. 3). Components can be placed in horizontal and vertical direction.
2) Pull various components of the window sealing plate assembly open, adjust their opening distance
to bring both ends of the assembly into contact with the window frame, and fix various components
of the assembly.
5 Installation and adjustment
