Split type air conditioner / User Manual 41 / 108 EN
40 / 112 EN
Split Type Air Conditioner / User Manual
8 Test run
8.1 Test run instructions
You should perform the Test Run for at least 30
minutes.
1. Connect power to the unit.
2. Press the ON/OFF button on the remote
controller to turn it on.
3. Press the MODE button to scroll through the
following functions, one at a time:
• COOL – Select lowest possible temperature
• HEAT – Select highest possible temperature
4. Let each function run for 5 minutes, and
perform the following checks:
List of Checks to Perform PASS/FAIL
No electrical leakage
Unit is properly grounded
All electrical terminals properly
covered
Indoor and outdoor units are
solidly installed
All pipe connection points do
not leak
Outdoor
(2):
Indoor
(2):
Water drains properly from drain
hose
All piping is properly insulated
Unit performs COOL function
properly
Unit performs HEAT function
properly
Indoor unit louvers rotate
properly
Indoor unit responds to remote
controller
C
During operation, the pressure
of the refrigerant circuit will
increase. This may reveal leaks
that were not present during
your initial leak check. Take time
during the Test Run to double-
check that all refrigerant pipe
connection points do not have
leaks. Refer to Gas Leak Check
section for instructions.
5. After the Test Run is successfully completed,
and you confirm that all checks points in List
of Checks to Perform have PASSED, do the
following:
– Using remote control, return unit to normal
operating temperature.
– Using insulation tape, wrap the indoor
refrigerant pipe connections that you
left uncovered during the indoor unit
installation process.
If ambient temperature is below 17°c (62°f)
You can’t use the remote controller to turn on
the cool function when the ambient temperature
is below 17°c. In this instance, you can use the
manual control button to test the cool function.
1. lift the front panel of the indoor unit, and raise it
until it clicks in place.
2. The MANUAL CONTROL button is located on
the right-hand side of the unit. Press it 2 times
to select the COOL function.
3. Perform Test Run as normal.
Manual control button
Manual control button
41 / 112 EN
Split Type Air Conditioner / User Manual
9 Care and maintenance
9.1 Cleaning your indoor unit
A
CAUTION! Always turn off your
air conditioner system and
disconnect its power supply
before cleaning or maintenance.
C
Only use a soft, dry cloth to
wipe the unit clean. If the unit is
especially dirty, you can use a
cloth soaked in warm water to
wipe it clean.
A
CAUTION! Do not use chemicals
or chemically treated cloths to
clean the unit.
A
CAUTION! Do not use benzene,
paint thinner, polishing powder
or other solvents to clean the
unit. They can cause the plastic
surface to crack or deform.
A
CAUTION! Do not use water
hotter than 40°C (104°F) to
clean the front panel. This can
cause the panel to deform or
become discolored.
9.2 Cleaning your air filter
A clogged air conditioner can reduce the cooling
efficiency of your unit, and can also be bad for
your health. Make sure to clean the filter once
every two weeks.
1. Lift the front panel of the indoor unit.
2. Grip the tab on the end of the filter, lift it
up,then pull it towards yourself.
3. Now pull the filter out.
4. If your filter has a small air freshening filter,
unclip it from the larger filter. Clean this air
freshening filter with a hand-held vacuum.
5. Clean the large air filter with warm, soapy
water. Be sure to use a mild detergent.
6. Rinse the filter with fresh water, then shake off
excess water.
7. Dry it in a cool, dry place, and refrain from
exposing it to direct sunlight.
8. When dry, re-clip the air freshening filter to the
larger filter, then slide it back into the indoor
unit.
9. Close the front panel of the indoor unit.
Remove air freshening filter from back of
larger fillter (some units)
Filter Tab
Filter Tab
Remove air freshening filter from back of larger fillter
(some units)
