4 Installation
4.1 Installation summary - indoor unit
Select Installation Location
Attach Mounting Plate
Determine Wall Hole Position
1 2
3
Drill Wall Hole
Mount Indoor Unit
STEP
8
Wrap Piping and Cable
(not applicable for some locations in North America)
Connect Piping
Prepare Drain Hose
Connect Wiring
(not applicable for some
locations in North America )
4
5
6
7
8
9
Select Installation Location
Drill Wall Hole
Prepare Drain Hose
Determine Wall Hole Position
Connect Piping
Wrap Piping and Cable
(not applicable for some locations in North America)
Attach Mounting Plate
Connect Wiring
(not applicable for some locations in North
America)
Mount İndoor Unit
15cm (5.9in)
2.3m (90.55in)
12cm
(4.75in)
12cm
(4.75in)
