Je bekijkt pagina 12 van 472

Microwave Oven / User Manual12 / EN

2.3 Installing the turntable

• Never place the glass tray upside down. The

glass tray should never be restricted.

• Both glass tray and turntable support must al-

ways be used during cooking.

• All food and containers of food must always

place on the glass tray for cooking.

• If glass tray or turntable support crack or break,

contact your nearest authorized service center.

2 Yourmicrowaveoven

Göbek (alt kısım)

Cam tabla

Döner tabla desteği

Döner tabla mili

Hub (underside)

Glass tray

Turntable shaft

Turntable support

3 Installation and connection

3.1 Installation and connection

• Remove all packing material and accessories.

Examine the oven for any damage such as dents

or broken door. Do not install if oven is damaged.

• Remove any protective film found on the micro-

wave oven cupboard surface.

• Do not remove the light brown Mica cover that is

attached to the oven cavity to protect the mag-

netron.

• Please observe the special installation instruc-

tions.

• The built-in cupboard shall not have a rear wall

behind the appliance. Minimum installation

height is 85 cm.

• The appliance is fitted with a plug and must only

be connected to a properly installed grounded

socket.

• The mains voltage must correspond to the volt-

age specified on the rating plate.

• If the plug is no longer accessible after installa-

tion, an all-pole isolating switch must be present

on the installation side with a contact gap of at

least 3 mm.

• Adapters, multi-way sockets and extension

cords must not be used. Overloading can result

with a risk of fire.

The accessible surface may be hot

during operation.

B

Do not trap or bend the power cable.

3.2 Installation Instructions

C

Please Read the Manual Carefully

Before Installation.

1 2 3

1. Adjust screw A

2. Screw B

3. Trim-kit plastic cover
