EN / 25
Recommended cooking pots/pans sizes
Cooking zone diameter - mm Pot diameter - cm
120 12 – 14
140 14 – 16
180 18 - 20
210 21 - 23
170x265 17 – 19 / 26 - 28
6.2 Operation of the hobs
To operate the vitro-ceramic hobs, the hob
control knobs are used. To obtain your de-
sired cooking level, switch the hob control
knob to the desired level.
The hob(s) may have 3, 6 or 9 operating
levels as per the model of your appliance.
You may select the relevant level for your
cooking type by referring to the table be-
low.
3 levels:
1: Heating
2 : Boiling, Resting
3 : Baking, Frying, Boiling
6 levels:
1 : Heating
2 – 3 : Boiling, Resting
4 – 6 : Baking, Frying, Boiling
Using the multi cooking-zones
ü Your appliance may be equipped with a
type A or B zones. Multi cooking-zones
allow cooking with pots with different
diameters on the same zone. When
these zones are turned on for the first
time, the zone at the center is turned
on. (The shaded area on the illustration
are central zones.)
1. To change the diameter of the active
zone, rotate the control knob clockwise.
Bring it to the symbol for type A zone,
and to the symbol for type B zone.
2. A “click” is heard whenever the zone dia-
meter is changed.
ð All central and external surfaces of the
multi cooking-zones start to operate.
The shaded areas of multi cooking-
zones shown below do not operate
by their own.
