Split type air conditioner / User Manual
43 / 135 EN
Outdoor unit dimensions (mm)
W×H×D
Mounting dimensions
Distance A (mm) Distance B (mm)
681x434x285 (26.8"x17.1 "x11.2") 460 (18.1") 292 (11.5")
700x550x270 (27.5"x21.6"x10.6") 450 (17.7") 260 (10.2")
700x550x275 (27.5"x21.6"x10.8") 450 (17.7") 260 (10.2")
720x495x270 (28.3"x19.5"x10.6") 452 (17.8") 255 (10.0")
728x555x300 (28.7"x21.8"x11.8") 452 (17.8") 302(11.9")
765x555x303 (30.1"x21.8"x11.9") 452 (17.8") 286(11.3")
770x555x300 (30.3"x21.8"x11.8") 487 (19.2") 298 (11.7")
805x554x330 (31.7"x21.8"x12.9") 511 (20.1") 317 (12.5")
800x554x333 (31.5"x21.8"x13.1") 514 (20.2") 340 (13.4")
845x702x363 (33.3"x27.6"x14.3") 540 (21.3") 350 (13.8")
890x673x342 (35.0"x26.5"x13.5") 663 (26.1") 354 (13.9")
946x810x420 (37.2"x31.9"x16.5") 673 (26.5") 403 (15.9")
946x810x410 (37.2"x31.9"x16.1") 673 (26.5") 403 (15.9")
If you will install the unit on the ground or on a
concrete mounting platform, do the following:
1.
Mark the positions for four expansion bolts
based on dimensions chart.
2.
Pre-drill holes for expansion bolts.
3.
Place a nut on the end of each expansion bolt.
4.
Hammer expansion bolts into the pre-drilled
holes.
5.
Remove the nuts from expansion bolts, and
place outdoor unit on bolts.
6.
Put washer on each expansion bolt, then
replace the nuts.
7.
Using a wrench, tighten each nut until snug.
A
Warning:
When drilling into
concrete, eye protection is
recommended at all times.
If you will install the unit on a wall-mounted
bracket, do the following:
A
Warning:
Make sure that the wall
is made of solid brick,
concrete, or of similarly
strong material. The wall
must be able to support at
least four times the weight
of the unit.
1. Mark the position of bracket holes based on
dimensions chart.
2.
Pre-drill the holes for the expansion bolts.
3.
Place a washer and nut on the end of each
expansion bolt.
4.
Thread expansion bolts through holes in
mounting brackets, put mounting brackets in
9 Outdoor unit installation
