Split type air conditioner / User Manual
31 / 135 EN
C
Note: The installation must be performed in accordance with the requirement of local and
national standards. The installation may be slightly different in different areas.
（1） （2）
1
2
3
4
6
7
8
9
10
11
3
1
2
4
5
6
7
8
11
5
Air-break switch
1. Wall mounting plate
2. Front panel
3. Power cable (some units)
4. Louver
5. Functional filter (On back of main filter - some
units)
6. Drainage pipe
7. Signal cable
8. Refrigerant piping
9. Remote controller
10. Remote controller holder (some units)
11. Outdoor unit power cable (some units)
C
Note on illustrations:
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor
unit may be slightly different. The actual shape shall prevail.
7 Unit parts
