Operation elements and connectors
Front panel of the Machinery-Tester MT 204-S
1 IEC connector for mains supply
2 Mains fuse (F1)
3 "ON/OFF" mains switch (with red pilot lamp)
4 Fuses for measurement functions RPE, RISO and HV (F2, F3)
5 Measurement function selector
6 HV lock key enabling / disabling the High-voltage test (flash test). The
key can be removed in HV off position only. Dangerous high voltage
will be applied to the output sockets (9) after pressing the
"START/STOP" button (7).
7 Button "START/STOP" starts or stops the selected measuring function
8 Pilot lamp "ON" (white), measurement active
9 Output sockets for all measurement functions
10 Pilot lamp "1000 V" (red), high voltage test active
11 Eyelet for fastening the holding cord of the device cover
12 Keyboard with 4 function keys SAVE, RCL (recall), MENU, EXIT
13 USB interface for PC (USB1)
14 Keyboard with four menu keys. Function of these keys is adjusted to the
actual function and can be seen in the bottom line of the LC-Display.
15 USB interface for USB barcode reader, USB keyboard or USB memory
stick (USB2)
16 Graphic LC-Display for measurement values, limit values and
parameters.
17 Front panel fastening screws (4 peaces)
Instrument cover
18 Brief instructions with limit values
19 Compartment for test leads and measurement accessories
Measurement accessories are stored in the compartment under the
instrument cover. Instrument cover holds also a card with brief instructions
and limit values according to EN 60204-1.
