W Follow the safety instructions. Connect both test

probes to the test object.

• The voltage tester switch ON automatically from a

voltage of approx. 10 V.

• The voltage is displayed by an LED row

3

• The 2100-Beta and 2100-Gamma also indicates the

voltage digitally on the LCD screen

9

.

• In the case of AC voltages the “+”and “-”LEDs are ON

simultaneously.

• The voltage testers feature an LED row with the

voltage indication 12 V, 24 V, 50 V, 120 V, 230 V,

400 V, 690 V.

• In the case of DC voltage the polarity of the indicated

voltage refers to the voltage tester test probe

2

.

• When the two push buttons

11

are pressed, the

internal load is applied.

• In case that 50 V AC or 120 V DC is reached or

exceeded, an audio warning by buzzer occurs.

WOperation duty cycle: Max. 30 s ON / 240 s OFF

Data Hold (2100-Beta / 2100-Gamma)

After pressing the push button

12

for ≥ 2 seconds , the

data hold function is activated and replies with a short

sound. The LCD screen shows “the last measured value” and

symbol “HOLD”. The hold function can be deleted manually

by pressing the push button

12

again. The data hold

function is now deactivated and replies with a short sound.

 Under data hold mode, the LCD screen will only show

the last saved measured voltage value. No auto refresh of

LCD screen reading under Data Hold mode whether the

voltage tester is connected to energized or non-energized

circuit. The LED voltage indicators

3

will always show the

actual voltage of the circuit under measurement.

Single-pole Phase Test

The single-pole phase test works from an AC voltage

of approx. 100 VAC.

During the single-pole phase test to determine

external conductors, the display function may be impaired

(e.g. with insulating personal protective equipment or at

insulated locations).

WThe voltage indication in single-pole phase test is

not sufficient to assure safety. This function is not suitable

to test for absence of voltage. This always requires a two-

pole voltage test.

Connect voltage tester’s test probe

2

to the test object.

The LED for single-pole phase test is ON in the display

5

depending on the voltage level.

Trip Test of RCD

For voltage tests in systems with RCD (earth leakage circuit

breakers) an RCD can be tripped with a 10 mA or 30mA

nominal leakage current on single phase AC 230 V power

system.

To do this, the voltage is tested between L and PE and

both pushbuttons

11

are pressed simultaneously. The RCD

should trip.
