5
UNPACKING AND INSPECTION
Your shipping carton should include:
1 2100-Alpha or 2100-Beta or 2100-Gamma
Voltage Tester
2 GS 38 protective probe caps
2 4mm Ø test probe extension (screwable)
2 1.5V alkaline batteries (installed)
1 User manual
If any of these items are damaged or missing, return the
complete package to the place of purchase for an exchange.
FEATURES
The Beha-Amprobe 2100 series are rugged and easy-to-use
two pole voltage testers for voltage and continuity checks.
The 2100 series are for electricians in industrial and
commercial applications for use in a wide voltage range
and safety rating are built according to latest voltage
tester standard EN 61243-3:2014 and are GS approved.
Voltage range:
2100-Alpha: 12…690 V AC/DC
2100-Beta: 6…690 V AC/DC
2100-Gamma: 6…1000 VAC / 6…1200 VDC
Safety rating (overvoltage category):
2100-Alpha / 2100-Beta: CAT IV / 600 V, CAT III / 690 V
2100-Gamma: CAT IV / 600 V, CAT III / 1000 V
All models offer voltage test by LED indicator, phase
rotation test, switchable load by two push buttons, single
pole phase test and continuity. Moreover, the series offers
a torch function for working in dark environments and
have an ingress protection degree of IP 64.
The 2100-Beta offers dual display for voltage test –
LED indicator and LCD screen – and data hold (HOLD).
The 2100-Gamma offers dual display for voltage test –
LED indicator and LCD screen with units – , resistance
measurement, low resistance indication, non contact cable
break detector / EF (electric field) and data hold (HOLD).
• Voltage Test Display
2100-Alpha: - by LEDs 12…690 V AC/DC
2100-Beta: - by LEDs 12…690 V AC/DC
- by LCD 6…690 V AC/ DC
2100-Gamma: - by LEDs 12…≥690 V AC/DC
- by LCD 6…1000 VAC/ 6…1200 VDC
• Automatic AC/DC voltage detection, indication of
polarity
• Audio indication when detected voltages above 50
VAC or 120 VDC
• Two pole phase rotation indication –no third hand
required. Separate indicators for “Right” and “Left”.
• Resistance measurement / low resistance indication
(2100-Gamma)
• Non contact cable break detector / EF (electric field)
(2100-Gamma)
• Data Hold (HOLD) (2100-Beta/2100-Gamma)
• Switchable load with two push buttons
• Trip of RCD (30 mA) by push buttons
• Single pole test for phase indication
• Continuity test with visual (LED) and audio indication
• LCD Backlight for dark environments (2100-Beta/2100-
Gamma)
• Torch light for dark environments
• GS approved, built according to EN 61243-3:2014
• Safety rating (overvoltage category):
2100-Alpha/2100-Beta: CAT IV / 600 V, CAT III / 690 V
2100-Gamma: CAT IV / 600 V, CAT III / 1000 V
• IP 64 splash-proof and dust-tight
• GS 38 protective probe caps
• 4mm Ø test probe extension (screwable)
• Quick single hand test on mains socket with 19 mm
contact distance
