BeamZ STB448 handleiding
Handleiding
Je bekijkt pagina 28 van 32
Auto
Sp 1-20
Auto Speed 1-20 (slow->fast)(Speed)
Auto mode, randomly run all effects
St 0-19
(Slow->fast)(Strobe)
Addr
7 CH
A001-A506
Each channel mode is a separate
address. Plug in the console and it
automatically enters DMX mode.
13 CH
A001-A500
82 CH
A001-A431
130 CH
A001-A383
135 CH
A001-A378
Shou
RGB
Sh00-68
Program Red/Green/Blue Show 1-68
Sp 1-20
Program Red/Green/Blue Speed 1-20 (slow->fast)（Speed）
St 0-19
Program Red/Green/Blue Flash 0-19 (slow->fast)（Strobe）
ACW
Sh00-36
Program Amber/Cool White Show 1-36
Sp 1-20
Program Amber/ Cool White Speed 1-20 (slow->fast)（Speed）
St 0-19
Program Amber/ Cool White Flash 0-19 (slow->fast)（Strobe）
Soud
Sou 1-3
Sen 1-9
3 types sound mode, adjustable sensitivity
SLAV
Slave
Slave
Colo
R000-255
Red (0-100%)
G000-255
Green (0-100%)
Bb000-255
Blue (0-100%)
A000-255
Amber (0-100%)
U000-255
White (0-100%)
St0-19
LED Strobe (slow->fast)
StAt
C101-C138
Red/Green/Blue static color（38 types static colors can select）
C201-C205
Amber/Cold White static color（4 types static colors can select）
St00-19
LED Strobe (slow->fast)
Set
dis
10s
Set the backlight time of the display panel from 10 seconds to continuous
brightness, with a factory default of 10 seconds
20s
30s
60s
On
dir
--->
Set the light direction to the right
<---
Set the light direction to the left
temP
50~65°C
Protection temperature setting, protection within the range of 50~65°C,
starting to reduce output power beyond this range
send
Yes
One-click set transmission function to send the current lamp channel mode
and temperature protection value to other lamps connected to this
lamp.(No other controller on the line)
Send
Info
ver
Vxxx
Software version
temp
XX C
Current lamp board temperature (degrees °C), if the temperature detection
line fails, boot prompt -RT-, the menu displays error
