On the label on the backside of the unit is indicated on this type of power supply must be connected. Check that the mains voltage corresponds to this, all

other voltages than specified, the light effect can be irreparably damaged. The product must also be directly connected to the mains and may be used. No

dimmer or adjustable power supply.

The unit has a powerconnector output on board. Depending on the local conditions several units can be linked by powerconnector in- and output. Connect

a maximum of four (when using 230V/16A) units in a row. Use an approved three-core cable with a cross-section of at least 1.5 mm². The installation

instructions of the manufacturer and the colour coding of the cable must be observed. Do not turn off the unit by turning the powerconnector but use the

power on/off switch or schuko!

Always connect the unit to a protected circuit (circuit breaker or fuse). Make sure the unit has an appropriate electrical ground to

avoid the risk of electrocution or fire.

Please consider the respective national norms during the installation! The installation must only be carried out by an authorized

employee or dealers!

This fixture has been designed to be hung. It is recommended for safety purposes, your lighting effect are properly mounted using a suitable hanging

clamp and safety cable. Items appropriate for safe and effective mounting are easily sourced from your lighting vendor.

International laser safety regulations require that lasers must be operated in the fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical

separation between the floor and the lowest laser light vertically. Additionally, 2.5 meters of horizontal separation is required between laser light and

audience or other public spaces.

Use of controls, adjustments, or performance of procedures other than what is specified herein may result in hazardous radiation

exposure!

• The installation of the fixture has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming

deformation.

• Always use the supplied mounting bracket to hang the fixture.

• The fixture should aid of a mounting bracket (not included) to the supplied mounting bracket to be confirmed.

• The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net. This secondary safety attachment

must be constructed in a way that no part of the installation can fall down if the main attachment fails.

• Make sure the area below the installation place is free from unwanted persons during rigging, de-rigging and servicing.

• The operator has to make sure that safety-relating and machine-technical installations are approved by an expert before taking into operation

for the first time and after changes before taking into operation another time.

• The operator has to make sure that safety-relating and machine-technical installations are approved by a

skilled person once a year.

• The fixture should be installed in the position where persons cannot reach.

• For your own safety and for others, we do strongly recommend you to use this laser emergency kill switch.

(ref.no: 152.958)

When installing the device, make sure there is no highly in inflammable material (decoration articles, etc.) in between a distance of

min 0.5 meter.

Follow below advice to enjoy a longer laser lifetime:

• Quick on/off switching of this device will reduce durability of the laser diode dramatically.

• Ensure that device does not get overheated:

o Switch off device when it is not needed. Diodes are switched on and can wear out even if

there is no visible laser output.

o Switch off device after 1 hour and let the laser cooling down for 15 minutes.

o Ensure that the fans and heat sinks are free of dust and dirt.
