How To Control The Unit

Three ways to operation:

A. Master/Slave operation

B. Easy sound active and Auto mode

C. Universal DMX controller

A. Master/Slave operation

The unit can be linked together in daisy chain as many as you need in master/slave mode to perform the great built-in

pre-programmed lighting shows triggered by music.

In Master/Slave mode refer to the DMX settings below:

Master unit: when working at Auto-run or Sound Control mode operation

Slave units: DMX start address MUST be set to 001. (First DIP switch = ON, all other

are OFF)

B. Easy sound active and Auto mode

Set sound active mode: Tenth DIP switch = ON , first to sixth DIP switch ON is mode of adjustable speed ,all other are

OFF

Set Auto mode: Ninth and Tenth DIP switch = ON ,first to sixth DIP switch on is speed mode ,all other are OFF, first to

sixth DIP switch ON is mode of adjustable speed ,all other are OFF

C. Universal DMX controller

When using a universal DMX controller to control the chain of units, you have to set DMX address by Dip switches from 1

to 9 to make sure all the units will receive its DMX signal.

Please refer to the following diagram to know how to address your DMX 512 system in the binary code.

DMX 512 Address Chart:

Dip-switches # 1 # 2 # 3 # 4 # 5 # 6 # 7 # 8 # 9 #10

Value 1 2 4 8 16 32 64 128 256 2-light show

5. DMX 512 Configuration

0: OFF 1: ON -: OFF or ON

Function

DIPSWITCH CHART

1 2 3 4 5 6 7 8 9 10

Sound

Speed selection

(Slow→Fast)

- - 0 1

Auto - - 1 1

DMX512

SET DMX ADDRESS FOR DMX MODE

Channel 1

11～200

DMX Auto

201～255

DMX Sound

Channel 2

0～255 No.1 LED Gobo

Channel 3

0～255 No.2 LED Gobo

Channel 4

0～255 No.3 LED Gobo

Channel 5

0～255 No.1 Motor Scanning

Channel 6

0～255 No.2 Motor Scanning

Channel 7

0～255 No.3 Motor Scanning

Master

Auto-run, Sound Control

Slave 1 0 0 0 0 0 0 0 0 0
