GB
Quick Guide
THANK YOU FOR PURCHASING A BAUKNECHT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.bauknecht.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
For all testing institutes:
2) Long cotton cycle: set wash cycle “Cotton ” with a temperature of 40°C.
3) Long synthetics cycle: set wash cycle “Synthetics “ with a temperature of 40°C.
* By selecting the “Spin & Drain” cycle and excluding the spin cycle, the washing machine will
drain only.
** The duration of the wash cycles can be checked on the display.
*** For Prewash press the “Temp.” button until the symbol lights up (only 90°).
****
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
4) The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as
the temperature and pressure of the incoming water, ambient temperature, amount of
detergent, load quantity and type, load balancing and any additional options selected.The
values given for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient
programme in terms of energy and water consumption for washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1. EXTRA RINSE / MUTE button
2. FINAL CARE / KEY LOCK button
3. ON/OFF button
4. STEAM HYGIENE button and indicator light
5. START/PAUSE button
6. RAPID button
7. SPIN button
8. START DELAY button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
Maximum load 7 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Add
Gar-
ments
(
)
Detergents and
Additives
Recommended
detergent
Residual
dampness % (****)
Energy
consumption kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load
(kg)
Dura-
tion
(h : m)
Pre-
wash
Wash
Fabric
softener
Pow-
der
Liquid
Setting Range 1 2 3
Eco 40-60 (1)
40 °C 40°C
1351 7,0 3:25
–
53 0,635 54 34
1351 3,5 2:40
–
53 0,445 44 32
1351 2,0 2:25
–
53 0,187 35 23
Cotton (2)
40°C
- 60°C
1400 7,0 3:40
–
50 0,980 75 45
Synthetics (3)
40°C
- 60°C
1200 4,0 2:55
–
35 0,860 60 43
Mixed
40°C
- 40°C
1400 7,0 **
–
–
– – – –
Delicates
40°C
- 40°C
1000 3,5 **
–
–
– – – –
White
40°C
- 90°C
1400 7,0 1:40
(***)
52 0,650 66 42
Anti Stain
40°C
- 40°C
1000 3,5 **
–
– – – –
Rapid 30’
30°C
- 30°C
1200 (4) 3,5 0:30
–
–
73 0,194 31 27
Spin & Drain *
– – 1400 7,0 ** – – – – – – – – – –
Rinse & Spin
– – 1400 7,0 ** – – –
– – – – – –
Refresh
– – – 1,0 ** – – – – – – – – – –
20°C
20 °C
- 20 °C
1400 7,0 1:50
–
–
52 0,160 64 22
Wool
40°C
- 40°C
800 1,5 **
–
–
– – – –
Anti Allergy
60°C 40°C - 60°C 1400 3,5 **
–
– – – –
Bed & Bath
60°C
- 60°C
1400 7,0 **
–
– – – –
Dosing required Dosing optional
DETERGENT DISPENSER DRAWER
compartment 1: Pre-wash detergent
(powder)
compartment 2: Detergent for the wash
cycle (powder or liquid)
If liquid detergent is used, it is recommended
that the removable plastic partition A
(supplied) be used for proper dosage.
If powder detergent is used, place the partition
into slot B.
compartment 3: Additives (fabric softeners,
etc.)
The fabric softener should not overow the grid.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
3
A
B
1 2
4
5
67
8
9
3
10
DISPLAY
