THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance,
pleaseregister your product on
www.register10.eu
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.bauknecht.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identi cation plate.
You can nd more information about your model online at https://eprel.ec.europa.eu/ which is the o cial EU EPREL product database.
After selecting the Product Category, enter the Model Identi er of the product. The Model Identi er is made up of letters and numbers
and can be found on the identi cation plate, as Mod. (see image on the right).
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.emeaappliance-docs.eu
• Alternatively, contact our After-sales Service (Using QR code in your appliance). When contacting our After-sales Service, please
state the codes provided on your product's identi cation plate.
EN
Before using the appliance carefully
read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/O" button.
5. Select the most suitable programme
for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Turn the machine
o by pressing the "On/O" button, open the door and pull the
clothing immediately out to prevent the formation of creases on
laundry.
If the machine is not switched o manually, after about a quarter
of an hour from the end of the cycle , the appliance turns o
automatically to save energy.
Note that some programme/option accords with "Crease Care"
system. This means that for some hours, after the end of the
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
Note that some models perform a nal cool tumble phase, for this
reason the fabrics may not feel hot.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
In case of power failure, it is necessary to press the "Start/Pause" button
to restart the cycle.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is xed correctly,
either to the dryer’s water tank, or to your domestic drainage
system. The dryer must be installed in a room with a
temperature ranging between 5°C and 35°C to ensure proper
operation. Before using the dryer make sure it has been in an
upright position for at least 6 hours.
Should you wish to change the opening side of the door,
please contact our After-sales Service. (See phone number in
the warranty booklet).
3 “
“
3 “
“
END
END
1
3
2
4
10
8
9
5 67
D
D
E
E
M
M
O
O
h
h
h
CONTROL PANEL
1 ON/OFF Button (hold for Reset)
2 Programme Selection Knob
3 Start/Pause
Options Buttons*
4 Crease Care
5 Dryness Level
6 Start Delay
7 Timed Drying
8 Cycle End
9 Gentle (hold for Key Lock)
10 Rapid (hold for Mute)
*Note: some models may have the wording in full instead of the icons.
INDICATORS
Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry
Cycle Phase: Drying - Cool Down - END End of Cycle
Empty water tank - Clean door lter - Clean bottom lter
Refer to troubleshooting section: Failure: Call after sales service
