ELECTRICAL CONNECTION

Electrical connection must be made before connecting the appliance to the electricity supply.

Installation must be carried out by qualied personnel who know the current safety and installation regulations. Specically, installation must be carried out in

compliance with the regulations of the local electricity supply company.

Make sure the voltage specied on the data plate located on the bottom of the appliance is the same as that of the home.

Regulations require that the appliance be earthed: use conductors (including the earth conductor) of the appropriate size only.

CONNECTION

• Connect the hob connectors (G) to the oven connectors (F), matching the colours and aligning the housing guides visible on the connectors’ top.

• Make the connection by pushing the connectors a ll the way in, making sure that the tongue clicks into place.

• Unscrew the nut of the earth screw (H)

on the oven's top cover and insert the main yellow/green earth wire, leaving the washer in place.

• Screw the nut back onto the screw and tighten it as far as it will go.

IMPORTANT: If the cooktop terminals do not correspond to the connection and colour indications on the cooktop/oven connection plate located at the top of

the oven, request the adaptor kit, code AMC 873, from the After-sales Service.
