EN
Daily Reference Guide
7
LOADING THE RACKS
CAPACITY: 15 standard place-settings
TOP RACK
The top rack provides
a targeted cleaning
Wash Zone for bowls,
mugs, even big plates
and cutlery that you’d
normally load in the
lower racks, making
extra space for the rest of the day’s dishes.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: a high po-
sition to place bulky crockery in the lower basket and
a low position to make the most of the tip-up supports
by creating more space upwards and avoiding collision
with the items loaded into the lower rack.
The upper rack is equipped with an Upper Rack height
adjuster (see gure), without pressing the levers, lift it
up by simply holding the rack sides, as soon as the rack is
stable in its upper position. To restore to the lower posi-
tion, press the levers A at the sides of the rack and move
the basket downwards.
We strongly recommend that you do not adjust the height of the rack
when it is loaded. NEVER raise or lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfold-
ed to optimize the arrangement of crockery in-
side the rack. Wine glasses can be placed safely
in the foldable aps by inserting the stem of
each glass into the corresponding slots. In the
case of the high position of the upper rack, aps
cannot remain in the vertical position.
Depending on the model:
• to unfold the ap there is needed to slide it up
and rotate or release it from the snaps and pull
it down.
• to fold the ap there is needed to rotate it and slide the ap down or pull
it up and attach the ap to the snaps.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should
ideally be placed at the sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can be used in a vertical position
when arranging plates or in a horizontal position (lower) to load pans and
salad bowls easily.
(loading example for the lower rack)
POWERCLEAN PRO
PowerClean Pro uses the special water jets
in the rear of the cavity to wash more inten
-
sively the highly dirty items. The lower rack
has a Space Zone, a special pull-out sup
-
port in the rear of the rack that can be used
to support frying pans or baking pans in an
upright position, thus taking up less space.
Placing the pots/casseroles faced to the
PowerClean Pro component please acti-
vate the POWERCLEAN on the panel.
How to use the PowerClean Pro:
1. Adjust the PowerClean Pro area G folding
down the rear plate holders to load pots.
2. Load pots and casseroles inclined ver-
tically in the PowerClean Pro area. Pots
have to be inclined towards the powerful water jets.
CUTLERY BASKET
It is tted with top grids for improved cutlery arrangement.
It must only be positioned at the front of the lower rack.
Knives and other utensils with sharp edges must be placed in the cut-
lery basket with the points facing downwards or they must be posi-
tioned horizontally in the tip-up compartments on the upper rack.
