EN / 34
1 Innermost glass panel
2 Inner glass panel*
3 Outer glass panel
* It varies depending on the product model. It
may not be available on your product.
3. As illustrated in the figure, raise the in-
nermost glass panel (1) slightly in direc-
tion “A” and pull it out in direction “B”
4. If your product is equipped with an inner
glass panel; Pull the glass holder con-
necting elements in the middle as illus-
trated in the figure to free them from the
glass panels.
4 Glass holder connecting element*
* It varies depending on the product model. It
may not be available on your product.
5. Repeat the same procedure to remove
the inner glass panel (2). The first step
to regroup the door is reinstalling inner
glass panel (2).
6. As illustrated in the figure, place the
glass panel so that it is inserted to the
plastic slot.
Otherwise the glass panel will not
seat completely and may get ex-
posed to vibration and break.
7. When installing the innermost glass
panel (1), make sure that the printed
side of the panel faces towards the in-
ner glass panel.
8. It is important that the lower corners of
the innermost glass panel are seated
into the plastic slots.
Otherwise the glass panel will not
seat completely and may get ex-
posed to vibration and break.
9. Please remember to place the glass
holding connecting parts into their slots.
10.Finally, press on the tabs of the profile
to make them seat into their slots again.
9.9 Cleaning the Oven Lamp
In the event that the glass door of the oven
lamp in the cooking area becomes dirty;
clean using dishwashing detergent, warm
water and a soft cloth or sponge and dry
with a dry cloth. In case of oven lamp fail-
ure, you can replace the oven lamp by fol-
lowing the sections that follow.
Replacing the oven lamp
General Warnings
• To avoid the risk of electric shock before
replacing the oven lamp, disconnect the
product and wait for the oven to cool. Hot
surfaces may cause burns!
• This oven is powered by an incandescent
lamp with less than 40 W, less than 60
mm in height, less than 30 mm in dia-
meter, or a halogen lamp with G9 sockets
with less than 60 W power. Lamps are
suitable for operation at temperatures
above 300 °C. Oven lamps are available
