GENERAL SAFETY WARNINGS
Class III- Class III appliance is designed to be supplied from a separated
extra-low voltage (SELV) power source.
For the safety of yourself and others, follow all instructions and take notice of all the
warnings. When adhered to, these safety precautions can reduce the risk of fire,
electric shock and injury. This product complies with Australian Safety standard
AS/NZS 62368.1 to ensure the safety of the product.
The RCM is a visible indication of a product’s compliance with all applicable
ACMA regulatory arrangements, including all technical and record-keeping
requirements.
IMPORTANT
• Environment: Do not use this product where
it is excessively hot, cold, dusty or humid, or
where it is exposed to strong magnetic fields
or long periods of sunshine.
• Water: Do not expose this product to water;
do not use it where it can fall into water
(such as near a pool, pond, bath etc.).
• Handling: Do not drop this product or shake
it vigorously to avoid damaging it.
• Usage: Only operate the device according
to the instructions in this manual. We
assume no responsibility for faulty use or
inappropriate handling.
• Usage: The equipment is not intended
for use by persons (including children)
with reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction by a person
responsible for their safety.
• Children: Supervise young children to
ensure they do not play with the device
inappropriately. Close supervision is
necessary when the device is used by or
near children.
• Cleaning: Clean the housing of the device
lightly with a dry or moist cotton cloth. Do
not use alcohol, thinners, benzene or any
other chemical cleaners.
WARNING – Electrical Safety This product is equipped with over-voltage and over-current protection
to safeguard internal components and ensure user safety.
Do not exceed the specified voltage or current limits.
Connecting the device to an unstable or overloaded power source may result in
malfunction, fire, or electric shock.
Ensure all power connections comply with the technical specifications provided in this
manual.
Do not use a charger or adapter that exceeds the product's specified ratings.
To connect the product, insert the USB connector firmly into a USB port on a
computer or other SELV power source at a safe low voltage (DC 5V 2A or 9V 2.22A)
via the supplied USB cable. Please always checking the marking on the product. before charging.
Well done, you made it.
Now sit back and relax... your product is automatically covered by a 1-year warranty.
How nice!
Operation or display is
abnormal
Display is not easy to
read
It is normal for the battery capacity to slowly drop after a certain
usage cycle.
Capacity drops
Ensure the battery of the product is charged.
Make sure the battery of the product is charged.
Product not
switching on
Wireless charging
not working
Check that your smart phone supports wireless charging.
If you have a smart phone case, you must remove it when charging.
Ensure your smart phone is facing up and aligned to the centre of
the wireless charging pad.
Remove any metal or other objects between the smart phone and
the wireless charging pad.
Troubleshooting
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by Hands (IP) Holdings Pty Ltd is under license. Other trademarks
and trade names are those of their respective owners.
Input USB-C 5V 2A or 9V 2.22A (20W Max.)
USB Output 5V 50mA
Battery Li-ion 3.7V 2200mAh, 8.14Wh
Wireless Output 15W Max.
Weight
Dimensions (L x W x H)
Storage Humidity
5%~60%RH
Operating Humidity
10%~35% RH
Operating Altitude
below 2000m
Operating Temperature
5°C~35°C
1000g (approx.)
245 x 125 x 87 mm
If the function is abnormal or the display is abnormal (such as
nothing is displayed on the screen) when the power is plugged
in, press POWER button 5 times to reset the product to
factory default.
Reset
Press POWER button 5 times to reset the product.
•
Handle Light
Press CLOCK button to switch the handle light.
Ambient Light
Press LIGHT button twice to turn on/off the ambient light.
When light is on, press LIGHT button to select the light mode.
Press SLEEP button to set the sleep timer for 30/60/90 mintues.
Sleep Timer
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
