10
INCASSO APPARECCHIATURA
Accertarsi del perfetto stato e della stabilità
del mobile nel quale saranno incassate le apparec-
chiature (Normativa DIN 68930).
Preparare un foro di incasso con le misure indicate in
fig. 5.
[mm]
37
37
340
490
5
É possibile accostare più apparecchiature serie
Thalas, considerando un interasse minimo tra
le apparecchiature pari a 2 cm (
fig. 6).
10
490
34
0
40
34
0
[mm]
370
370
10
6
BUILT-IN UNIT INSTALLATION
Make certain that the cabinet in which you
will be installing the appliance is in perfect condition
and completely stable (Standard DIN 68930).
Prepare an embedded hole with measurements as speci-
fied in
figure 5
It is possible to install additional Thalas appli-
ances; there must be a minimum clearance of 2
cm between the appliances (
figure 6).
