After the dual watch is turned off, the radio setting menu will automatically add "Singal Mode". After turning on the single display mode, the radio
will display the channel name, frequency and channel sequence on the same screen.
6.4 Manual Programming (Channels Memory)
Memory channels are an easy way to store commonly used frequencies so that they can easily be retrieved at a later date.
The radios features 999 memory channels that each can hold: Receive and transmit frequencies, transmit power, group signaling information, bandwidth,
ANI/ PTT-ID settings and a six character alphanumeric identifier or channel name
1
.
Frequency Mode vs. Channel Mode
In standby mode, press and hold the key to switch between frequency (VFO) mode and channel (MR) mode.
These two modes have different functions and are often confused.
Frequency Mode (VFO): Used for a temporary frequency assignment, such as a test frequency or quick field programming if permitted.
Channel Mode (MR): Used for selecting preprogrammed channels.
Ex 1. Programming a Channel Repeater Offset with CTCSS Tone
EXAMPLE New memory in Channel 10:
RX = 432.55000 MHz
TX = 437.55000 MHz (This is a (+ 5) Offset)
TX CTCSS tone 123.0
(1) Press the key to switch between menus.
(2) Press and hold the key to set the radio to VFO mode, and the VFO icon is displayed on the right.
(3) [5] [1][7] [1] [0] Deletes Prior Data in channel (Ex. 10)
(4) [5] [5] 123.0 Selects desired TX encode tone (Ex 123 CTCSS)
(5) [5] [1][4] [0][5] Enter the OFFSET frequency (Ex. 5.00MHz)
(6) [5] [1][5] [2] Select the offset direction (Ex. positive offset
）
(7) Enter RX frequency (Ex. 43255000) Enter RX frequency (Ex. 43255000)
(8) [5] [1][6] [1][0] Enter the same channel (Ex 10)
-->> channel has been added
(9) Press and hold the key to return to the MR mode and the channel number will reappear.
Ex 2. Programming a Simplex Channel with CTCSS tone
EXAMPLE New memory in Channel 10:
RX = 432.6500 MHz
TX CTCSS tone 123.0
(1) Press the key to switch between menus.
