4.3 Main keypad controls

• key: MENU key, It is used for activating the MENU, choose each MENU selection and confirm the parameter.

In standby mode, press and hold the key to switch between frequency (VFO) mode and channel (MR) mode.

When listening to broadcast FM, the key switches between 65-75 MHz and 76-108 MHz bands.

•▲ key: Press it for more than 2 seconds, the channel and frequency will move upwards rapidly; in SCAN mode, press this control to move the scanning

upwards.

•▼ key: Keep it pressed it for more than 2 seconds, the channel and frequency will move downwards rapidly; in SCAN mode, press this control to move the

scanning downwards.

• key: EXIT key, press to exit the Menu and functions.

• Numeric keypad

With these keys you can input the information or your selections on the radio. In TX mode, push the number keys to send a corresponding DTMF code.

• Key

A short momentary press of the key enables the reverse function.

The radios features a keypad lock that locks out all keys except for the three side keys.

To enable or disable the keypad lock, press and hold the key for about two seconds.

• key

When listening to broadcast FM a momentary press will start the scanning. Scanning in broadcast FM will stop as soon as an active station is found,

regardless of scanner resume method.

To enable the scanner, press and hold the key for about two seconds.

Short press the key to quickly enter the DTMF dialing.

5.BASIC OPERATIONS

5.1 Power on the radio

• Turning the unit on

To turn the unit on, simply rotate the Volume/Power knob clockwise until you hear a "click". If your radio powers on correctly there should be an audible double

beep after about one second and the display will show a message or flash the LCD depending on settings for about one second. Then it will display a

frequency or channel. If the Voice prompt is enabled, the voice will announce "frequency mode" or "channel mode".

• Turning the unit off

Turn the Volume/Power knob counter-clock wise all the way until you hear a "click". The unit is now off.

5.2 Adjusting the volume
