26
Press to enter the function. Press the / keys to enable (ON) the function, then press key for
confirmation.
To return to the standby mode press key.
Using the stopwatch timer:
When this function is ON, press key to start counting; Press key again to re-start counting.
To exit the function, stop the counting first, and then press the key.
6.8 DTMF
DTMF is an in-band signaling method using dual sinusoidal signals for any given code. Originally developed for telephony
systems, it has proved a very versatile tool in many other areas.
In two-way radio systems, DTMF is most commonly used for automation systems and remote control. A common example
would be in amateur radio repeaters where some repeaters are activated by sending out a DTMF sequence (usually a simple
single-digit sequence).
DTMF frequencies and corresponding codes
1209Hz
1336Hz
1477Hz
1633Hz
697Hz
1
2
3
A
770Hz
4
5
6
B
852Hz
7
8
9
C
941Hz
*
0
#
D
The radios has a full implementation of DTMF, including the A, B, C and D codes.
The numerical keys, as well as the , and , keys correspond to the matching DTMF codes as you would expect. The A,
B, C and D codes are located in the ,, and keys respectively.
To send DTMF codes, press the key(s) corresponding to the message you want to send while holding down the PTT key.
If you have the keypad lock enabled on your radio, you can still send DTMF tones the regular way without having to unlock
your radio.
