Deleting a channel (DEL-CH)
VFO mode and in standby mode, press [MENU] [3] [MENU] [1] [6],the screen will display “DELCH”.
Press [MENU] to enter the function. Press the ▲/▼ buttons or rotate the encoder to select the channel you want to delete, then
Press [MENU] to confirm.
To return to the standby mode Press [EXIT].
NOTE: Channel 1 cannot be deleted.
Main Band/Sub Band Switch
In standby mode, press the [A/B] key to toggle between the A and B bands to switch between the main/sub bands.
The
main band is the highlighted band. The darker displayed band is the sub-band.
VFO/Channel Switch
Press the [V/M] button to switch between VFO and channel display.
VFO mode will display the VFO icon.MR mode will display the channel serial number.
Setting the VFO Frequency
Turn the radio to VFO mode, then press the [A/B] key to switch to the main channel.
Operation 1: Input the VFO frequency directly with the keypad.
Operation 2: Press the ▲/▼ button or rotary encoder to
adjust the VFO frequency in the set frequency step.
Call Service
All radios in the group must be set to the same channel and sub-code to communicate.
To ensure optimal reception volume, keep the distance between the microphone and your mouth at 2.5 cm to 5 cm when
transmitting.
-Initiate a call: Select a channel, press and hold the [PTT-A] key, the radio transmits on segment A (upper screen) and the red
indicator light is always on. The
n speak into the microphone with normal voice tone.
Press and hold the [PTT-B] key, the radio transmits on the B segment (lower screen), and the red indicator light is always on. Then
