18
BASIC OPERATIONS
1. Power on the Radio
Turn on the radio by turning the [Power/Volume] switch clockwise till a click is heard, and the LCD displays will show a
start-up message, and you will hear a beep after 7 seconds.
2. Adjust Volume
Rotate the [Power/Volume] knob to adjust the volume. Turn clockwise to increase the volume and counterclockwise to
decrease the volume.
3. Main Band/Sub Band Switch
Press the [A/B] key to switch the main channel to the other channel if there is 2 channels shown on the display. The
channel indicated by the arrow is the main channel.
4. VFO/Channel Switch
Press the [VFO/MR] key to switch between VFO and channel display.
5. Set Up VFO Frequency
Press the [VFO/MR] key to tune the radio to VFO mode, then press the [A/B] key to switch to the main band, the VFO
frequency can only be set on the main "arrow" channel.
Operation 1: Input the VFO frequency directly by the keyboard.
Operation 2: Press the or navigation keys to adjust the VFO frequency in preset steps.
6. Selecting a Zone
A zone is a group of channels with the same property. The radio supports up to 150 zones, with a maximum of 32 channels
per zone. To select a zone, do one of the following:
