12
PREPARATION
Assembly
Before the radio is ready for use we need to attach the antenna and battery pack, as well as charge the battery.
1. Installing / Removing the Battery
Before attaching or removing the battery make sure your radio is turn off by turning the power/volume knob all the way
counter-clockwise.
(1) Installation
Make sure the battery is aligned in parallel with the radio body with the lower edge of the battery about 1-2cm below the
edge of the radio.
Once aligned with the guide-rails, slide the battery upward until you hear a click as the battery locks in place.
(2) Removal
To remove the battery, press the battery release above the battery pack, as you slide the battery downward.
2. Installing / Removing the Antenna
(1) Installing the Antenna: Screw the antenna into the connector on the top of the transceiver by holding the antenna at
its base and turning it clockwise until secure.
(2) Removing the Antenna: Turn the antenna counter-clockwise to remove it.
3. Installing / Removing the Belt Clip
(1) Installing the Belt Clip: Place the belt clip above the corresponding holes on the back of the radio, and screw it into
place clockwise with the two supplied screws.
(2) Removing the Belt Clip: Unscrew counter-clockwise to remove the belt clip.
