FLOOR MODEL GAS DECK OVEN OPERATION MANUAL
11
CLEANING AND MAINTENANCE
Troubleshooting Chart
PROBLEM PROBABLE CAUSE REMEDY
No Pilot Light Gas valve feeding oven may be in the
closed position
Turn gas valve on. Relight pilot.
Main Burner(s) do not light Gas valve feeding oven may be in the
closed position
Turn gas valve on. Relight pilot.
Thermopile may not be positioned in pilot
flame.
Ensure that the tip of thermopile is in pilot
flame.
Thermopile may be defective Call local authorized Bakers Pride Service
Agent.
Oven too Hot Thermostat set too high. Lower the thermostat setting and see if
flame reduces in size. Allow several hours
for heat to regulate.
Thermostat may be defective Call local authorized Bakers Pride Service
Agent.
Bottom of pies are
undercooked
If the same area of the deck is used
repeatedly, the deck temperature in that
area will be reduced.
Rotate pies to unused areas of the bake
deck that are hotter and will cook the
bottoms faster.
Micro slides are open too much. Close micro slides (pull out) until desired
combination is reached. This will help
decrease top heat.
Bottom of pies burn before
toppings are cooked
Deck temperature too hot - especially
during slow periods.
Reduce Thermostat setting by 50° - 75°
below normal bake temperature. When
decks cool begin cooking and immediately
increase the thermostat setting by 50° -
75°.
Micro slides are closed too much Open micro slides (push-in) to increase top
heat.
Oven was left “ON” overnight Oven must be turned to “Pilot” position
overnight. It should not be left on a high
temperature setting.
Exhaust fan too powerful. Reduce fan speed.
Pies cook Unevenly Area’s adjacent to oven walls are generally
hotter.
Rotate pies (180°), once during each bake
or keep to the center of oven.
Oven does not turn On or Off
on time. (Ovens equipped w/
auto oven starter only)
Power cord not plugged in. Plug unit in.
Electrical outlet fuse/circuit breaker is
tripped.
Replace fuse or reset circuit breaker.
Timer incorrectly set. Reset Timer.
Unit takes too long to reach
temp.
Gas volume or gas pressure may be
inadequate.
Contact gas supplier.
Call local authorized Bakers Pride Service
Agent.
