10 |General Information and Instructions
5. Always transport in an upright position.
6. Do not smoke when transporting your cylinder.
7. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve
outlet that is provided with the cylinder valve.
Other types of cap or plugs may result in leakage of propane.
CYLINDER SPECIFICATIONS
When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications
for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders,
Spheres and Tubes for Transportation of Dangerous Goods; and Commission, as applicable; and provided with a listed over-filling
prevention device (OPD), and provided with a cylinder connection device compatible with the connection for outdoor cooking
appliances.
The cylinder must also be equipped with:
• A shut-off valve terminating in a Type 1 gas cylinder valve ou
tlet.
• A Type 1 valve that prevents gas flow until a positive seal is obtained.
• An arrangement for vapor withdrawal.
• A collar to protect the cylinder shut-off valve.
• A safety relief device having direct communication with the vapor space of the cylinder.
• A listed over-filling prevention device (OPD).
WARNING:
A frosty cylinder valve indicates possible gas overfill. Close the LP valve and call your dealer immediately.
LP GAS CYLINDER (NOT SUPPLIED WITH THIS GRILL)
• The LP (Liquid Propane) gas cylinder specifically designed to be used with this grill must have a 20 lb. (9.1 kg) capacity
incorporating a Type 1 cylinder valve and an over-filling protection device (OPD).
• This grill is designed to fit Blue Rhino, Worthington, Manchester, or SMPC brand 20 lb. (9.1 kg) cylinders. Other brand DOT
cylinders may fit this grill if the cylinder has similar dimensions of the top and bottom rings.
• DO NOT connect this grill to an existing #510 POL cylinder valve with Left Hand threads. The Type 1 valve can be iden
tified with the
large external threads on the valve outlet.
• DO NOT connect to a propane cylinder exceeding this capacity.
• DO NOT connect to a cylinder that uses any other type of valve connection device.
• Other cylinders may be acceptable for use with the appliance, provided they are compatible with the appliance retention means
and accompanied by illustration depicting the cylinder mounted to the appliance, utilizing the cylinder retention means and the
point of contact between the cylinder and t
he retention means.
