ASSEMBLYASSEMBLY

109

• If assembly required:

Underneath the walker,

thread the end of the

support strap through

the loop on the seat

bottom. Slip the strap

through the slot at

the end of the height

adjustment bracket

(Fig. 3a).

• Next thread the

support strap through

the opening in the

rectangular D-ring and

pull snug (Fig. 3b).

• Loop the D-Ring

through the support

strap (Fig. 3c).

Fig. 3b

Fig. 3c

Fig. 3a

• To remove the seat fabric

reverse steps 3c, 3b and

3a, followed by the reversal

of steps 2c through 2a.

Fig. 4

Fig. 7

Fig. 5

Fig. 6

TO REMOVE THE SEAT FABRIC

Front

Back

FRONT WHEELS

• Place walker on a solid

at surface with bottom of

base facing upward. Insert

the pins of the front wheels

into their housing, pressing

them until they snap into

position. Please check

that wheels are locked into

place before proceeding

(Fig. 5).

REAR WHEELS

• Insert the pins of the rear

wheels into their housing,

pressing them until they

snap into position. Please

check that wheels are

locked into place before

proceeding (Fig. 6).

• For replacement / removal,

see Step 13.

STOPPERS

• Push the stopper into the

housing completely

(Fig. 7). Repeat for the

other sides.

• Ensure to apply enough

pressure when inserting

the stoppers.

• The Stoppers are there for

Stair Safety reasons, do NOT

remove the stoppers unless

for replacement purposes. For

removal, see Step 12.
