12
13
ASSEMBLY MONTAJE ASSEMBLY MONTAJE
7) • To assemble the child seats: Guide
the the frame with the plastic tab
facing down (Fig. 7a) into the arm
slots in the back of the seat. Insert
the frame fully into the slot and
repeat for the other side (Fig. 7b).
• With the frame inside the ap, snap
the buttons closed to secure it to the
child seat (Fig. 7c). Repeat for the
other side.
• Para ensamblar los asientos para
niños: Guíe el marco con la pestaña
de plástico hacia abajo (Fig. 7a) en
las ranuras para los brazos en la
parte posterior del asiento. Inserte el
marco completamente en la ranura y
repita para el otro lado (Fig. 7b).
• Con el marco dentro de la solapa,
cierre los botones para asegurarlo al
asiento para niños (Fig. 7c). Repita
para el otro lado.
NOTE: USE BOTH SEATS AT THE
SAME TIME (Fig. 7d).
• To install the child seats: Uncover the
fabric covering the rails by undoing the
hooks and loops.
• Make sure the plastic tab on the back of
the child seat is securely hooked onto
the wagon rail (Fig. 7e).
• Line up the plastic tabs on the child seat
with the rails (Fig. 7f) on the wagon
frame (Fig. 7g & Fig. 7h).
• Push the plastic tabs on the child seat
so they attach to the rails rmly
(Fig. 7i).
NOTE: The tabs should be parallel to
the side of the wagon.
• Fasten the hooks and loops on the side
of the child seats to the inside of the
wagon frame (Fig. 7j).
• To uninstall the child seats: Pull the
plastic tabs outward and lift to remove
(Fig. 7k).
Fig. 7e
Fig. 7d
Fig. 7a
Fig. 7b
Fig. 7c
Fig. 7f
CHILD SEATS
ASIENTOS PARA NIÑOS
