Names of Machine Parts
10
Measurements on the needle plate, bobbin cover (with
markings) and needle plate cover
The measurements on the bobbin cover are references for
patterns with a middle (center) needle position. The
measurements on the needle plate and the needle plate cover
are references for stitches with a left needle position.
1 For stitches with a middle (center) needle position
2 For stitches with a left needle position
3 Middle (center) needle position <inch>
4 Middle (center) needle position <cm>
5 Middle (center) needle position on the bobbin cover
(with markings) <inch>
6 Left needle position on the needle plate cover <inch>
■ Embroidery unit
1 Embroidery frame holder (page 88)
2 Frame-securing lever (page 88)
3 Embroidery unit connection (page 84)
4 Carriage (page 84)
5 Release button (page 85)
a
b
c
d
e
f
a
b
d
e
c
