5-Thread Safety Stitch
The 5-thread safety stitch is perfect for all types of woven fabrics ranging from fine to heavyweight.
This stitch is designed to seam and overlock the fabric edge in one step, thus creating a garment
industry standard stitch. As well as woven fabrics, the 5-thread safety stitch is for stabilizing knits,
sweater knits and long seams on woven fabrics.
The 5-thread safety stitch is a combined stitch of a 3-thread overlock and 2-thread chain stitch.
With the option of three different seam widths depending on the chain/cover stitch needle posi
-
tion. The varied widths allow versatility when working with different types of fabrics.
For 5-Thread Safety Stitch:
1. Use standard cutting blade cover.
2. Thread the upper, lower and chain loopers.
3. Thread the chain needle, C-1, C-2 or C-3, and O-1 overlock needle (See illustration).
4. Engage the upper cutting blade and set the stitch width at 7.5.
5. Select "A" on the Stitch Selector.
Note: For each stitch variation (width) refer to the settings chart on page 50.
Instructions for Upper/ Lower, Chain looper port, Overlock /Chain Needle(s) threading (See
pages 19-24).
7.0
7.5
3
4
2
5.0
4.5
BL
2
O
2
1
1
3
4
C3C3
O1
O1
CL
CL
LL
LL
UL
UL
C
O
M
B
I
N
A
T
I
O
N
S
T
I
T
C
H
49
