18 | www.BabyLock.com
Rear Handlebars (Oponal Accessory)
1. Locate the four 4mm hex screws for the rear handlebars and the 4mm Allen wrench.
2. Align the four holes in the handlebars with the
holes on the back of the machine.
3. Slide the bolts into holes unl they stop. Use
the 4mm Allen wrench to rmly ghten the
bolts and securely fasten the handles to the
back of the machine.
4. Connect one end of the RJ45, or network style,
phone cord into the handlebars and the other
end into the machine’s back panel.
5. Install the back handlebar display to the
handlebar with the four small screws using the
2.5mmAllen wrench.
Connect the USB mini B connector to the back
of the machine. You will need the other end for
the display later. Note that this cable powers
the display. The round power input to the
display is not used.
 IMPORTANT: See To aach labels to the
handlebars in the Congurable Handlebar
Buons topic on the previous page.
NOTE: Aer installing and plugging in the handlebar(s) and the touch-screen display(s), plug in
the power cord and test them by turning the machine on, using the rear power switch and then
the power buon on the front le side of the machine. If nothing appears on the touch screen(s),
check that the handlebar cable(s) are plugged in securely, that your machine is turned on, and that
the power cord is plugged into the machine as well as into a power source. If everything is working,
turn o and unplug the machine and connue the installaon.
