4
To Amp
bypass harness
(not included)
A
2-Pin
Connect 2 Pin
LD-BASSKNOB
20-Pin
LED
FRONT
REAR
SUB
2 PIN
20 PIN
CHIME VOL
UPDATE
PORT
Interface
R
LD-PAW-FD2
2-Pin
RCA Cables
(sold separately)
8-Pin
Blue/White - Amp Turn-On Wire
LD-PAW-EXT
2 of 2
C
Factory Radio
*BACK*
22-Pin
22-Pin
Factory Radio Harness
LD-BASSKNOB
Factory Radio
*SCREEN*
54-Pin
54-Pin
Connect D to E,
disregard
F.
D
E
F
Connect A to C.
Voice Prompts (Navigation models)
*
Amplified
Chime volume
is not used in
this application.
*
A Toslink cable can
be used to provide 2
channel audio to an
amplifier/processor
*
**
LED
FRONT
REAR
SUB
2 PIN
20 PIN
TOSS
LINK
CHIME VOL
UPDATE
PORT
Interface
2-Pin
30
86
85
87
To 12v
Constant
If connecting multiple amps, Metra recommends incorporating
an SPDT Relay (not included). Metra SPDT Relay part #: E-123
SPDT Relay
Aux Ground output for accessories
TOSLINK
ADDING AN AMPLIFIER/AMPLIFIERS TO A FACTORY SYSTEM
