Page 10 of 78
MXNET 1G USER MANUAL
1.2 Before You Begin
MXNet does not require the encoders and decoders to be connected in any specific order on the
network switch, meaning they can be placed on adjacent ports right next to each other and the
system will function without issue. However, for best results (especially when managing highly
complex systems with dozens of endpoints) a certain degree of design and planning is highly
recommended and can save precious time when it comes to installing, testing, and implementing
features on the system.
Read through this document in its entirety and ensure that the following required items are available:
MXNet 1G Encoder (AC-MXNET-1G-E, AC-MXNET-1G-E-AVDM, AC-MXNET-1G-EWP, or AC-
MXNET-1G-EV2)
MXNet 1G Decoder (AC-MXNET-1G-D or AC-MXNET-1G-DV2)
MXNet CBOX for control and Mentor web interface (AC-MXNET-CBOX)
MXNet 1G Network Switch (AC-MXNET-SW10, AC-MXNET-SW24, or AC-MXNET-48) or one that
meets MXNet requirements (see Third-Party Network Switch Requirements
)
Source devices, displays, and any other devices that will be used in the system
1.3 Some Helpful Suggestions
Make a list of all the devices in the system, including the sources and displays, model numbers
and SKU’s, MAC addresses and assigned IP addresses, along with any accessories such as rack
equipment, power sources, cable types and lengths.
Create a diagram or flow chart to indicate the starting and end points of the network cable
runs, as well as any schematics, diagrams, and other supporting documentation for easy
future reference.
Label the connections in the rack to their corresponding endpoints or ports on the network
switch.
For larger projects, consider grouping the encoder cables next to each other on the network
switch and likewise for the decoders.
1.4 Network Cabling Tips
Everything about a successful MXNet installation revolves around the network cabling itself. Keep in
mind that the quality, distance, and handling of the cable can all affect the signal speed and data
stream. Generally speaking, the higher the video resolution and the longer the run, the better the
cabling should be.
When terminating network cables, do not untwist the wires unnecessarily. Make sure to not untwist
more than ½ inch, preferably ¼ inch. Wires are twisted for good reasons:
1. Cancels out EMI (Electromagnetic Interference)
2. Cancels out crosstalk from neighboring conductors
For most applications, Cat5e (or better) is recommended for MXNet.
