AVPROEDGE ~ 2222 E 52ND STREET N, SIOUX FALLS, SD 57104 ~ 1.877.886.5112 ~ +.605.274.6055 ~ SUPPORT@AVPROEDGE.COM
7
CONNECTING
The AC-MV-41 can be controlled using the USB-C port, 3-pin RS-232, or over TCP/IP using
the LAN connection. For initial setup, it is recommended to connect the matrix to a local
area network (LAN) and use a computer on the same network in conjunction with the built-
in WebUI. After making all physical connections, the first step will be to check for Firmware
Updates. The below steps are an example of this setup. Other control options are covered in
separate sections of this user manual.
1. Grounding - Attach the included yellow ground strap to the back of the AC-MV-41 chassis
and secure the other end to a grounded object for safety.
2. HDMI Input Sources - Connect your source devices to the AC-MV-41 HDMI input ports.
3. HDMI Output Device - Connect your sink/display device to the AC-MV-41 HDMI output
port.
4. Network LAN Connection - Use a LAN cable to connect the AC-MV-41 to your local
network via the LAN port.
5. Powering on Input Sources - Power on input devices connected to the AC-MV-41.
6. Powering on Output Devices/Displays - Power on output devices connected to the
AC-MV-41.
7. Powering on the Multiviewer - Secure the 12VDC 5A power supply to the AC-MV-41, then
connect to an AC mains power outlet.
Note: All devices and power supply connections must be secure for correct operation.
