SHARK S8X PLUS
8CH Video Switcher
1
1. Introduction
1.1. Overview
SHARK S8X PLUS, featuring a 17.3-inch FHD IPS switcher, supports 8-ch 3G-SDI and 2-ch 4K HDMI
input, with frame synchronization output and an AUX input (supporting video player, UVC, streaming,
NDI). Outputs include 2 HDMI, 4 SDI, and 1 HDMI multiview with customizable output source and
format option. It supports RTMP(S)/SRT/RTSP/NDI streaming, recording and playback via USB/SD
card/2.5-inch SATA, and UVC lossless capture. The switcher offers chroma key, luma key,
customizable PIP×3, POP, DSK, and LOGO overlay. For Audio function, it provides two XLR/TRS
balanced inputs with 48V phantom power and a 3.5mm stereo input, supporting mixing of 8
embedded video audio channels and two external audio inputs. It also features 8-channel PTZ control
with rate, preset, focus control, and manual/auto exposure and color control. The switcher supports
macro script functionality for effortless automation of operations a, meeting professional live
streaming and production needs.
1.2. Main Features
17.3-inch FHD IPS display
Inputs: 6×3G-SDI and 2×SDI/4K HDMI, 1×BNC REF, 1×AUX (internal interface)
Multi-view source routing function, supporting the definition of any input signal to any specified view
AUX input: Video playback/UVC CAM/network pull stream/NDI
Outputs: 2×HDMI(A/B) PGM (configurable), 4×SDI(A/B) PGM (configurable), 1×HDMI MV (source
configurable), 1×REF output
Streaming: RTMP(S)/SRT/RTSP/NDI(Optional)
Recording and playback: USB flash drive/SD card/2.5-inch SATA
USBC port for UVC lossless capture
Chroma key, luma key, custom position and size PIP×3, POP, DSK, LOGO overlay
Transition: T-bar/Auto/Cut
Professional XLR audio input and output, supporting 48V phantom power
Audio: 8×input video embedded audio & 2×XLR/TRS balanced & 3.5mm stereo input; 3.5mm stereo &
XLR balanced output
8-channel PTZ control, supporting PTZ speed setting, preset position setting and calling,
automatic/manual white balance, automatic/manual color and automatic/manual focus control
Macro script function, supporting macro recording, playback and user editing of macro scripts
Tally GPIO port
