SHARK S8X PLUS
8CH Video Switcher
32
The FTB/MUTE speed can be adjusted in the menu from 0-3s, which is the entire switching time between
FTB and MUTE. For example, by setting the speed to 2.5s, the PGM video will fade to black and the
audio will fade to silence in 2.5s.
(2) FTB plus MUTE
The FTB can also come with a mute follow function. Turning on the Mute Follow button in the menu will
turn the PGM black and mute it.
14.Audio Settings
Users can precisely adjust the level of the 8 embedded audio channels as well as the 2 XLR/TRS/3.5mm
audio inputs by accessing the audio interface in the menu. The audio status is displayed in real-time on
the bottom area of the status page, making it easy for users to check and adjust accordingly at any time.
ON = audio on, AFV off, AFV = audio on, AFV effective.
14.1.Master Audio
Master audio is an audio control for PGM output. It can be mixed audio or AFV audio. User can turn on/off
the master audio or adjust audio volume.
14.2.AFV Audio Follow Mode
The audio of each SDI and HDMI channel can be set to AFV (Audio-Follows-Video). When the HDMI
audio mode of a channel is set to AFV, the audio will be turned on only when the PGM switches to that
HDMI. For example, if the audio mode of IN 1 is set to AFV, when the video switcher switches IN 1 to the
video source of PGM, the embedded audio of IN 1 will be turned on.
All Follow Functions（（Follow All）：In audio settings, "Follow All" usually means that the audio signal
will follow the switching of the video signal without the need to adjust the audio source separately. This
means that when you switch between different video input sources, the audio will automatically switch to
