SHARK S8X PLUS
8CH Video Switcher
8
2. Audio Control
Users can configure the audio for each channel, supporting mixing,
AFV mode, volume adjustment and master volume/headphone
output/PGM output volume control.
3.Key source control
Supports chroma key and luma key, PIP×3, DSK, LOGO quick switch,
and real-time adjustment of size and position.
KEY1-3: The functions of KEY1-3 can be enabled in the menu,
including CHROMA, LUMA, and PIP.
DSK: Enable Downstream Key
LOGO: Add logo from USB disk, enable logo overlay
ON AIR: Enable the corresponding Chroma/Luma/DSK/PIP/Logo on
the PGM
SIZE: Customize the size of KEY1-3, the size can be adjusted freely.
LOGO:Add logo from USB disk, enable logo overlay
POS.H: Setting the horizontal position of KEY1-3 in the screen
POS.V: Setting the vertical position of KEY1-3 in the screen
SOURCE: Select the desired source for the picture
TIE: DSK is usually used to overlay a logo or title directly onto the
PGM. But if you want the downstream keyer to work in AUTO or T-Bar,
just turn on TIE.
F1-F6: Customizable shortcuts, menu-configurable for use with macros
or other frequently used functions
4.Recording & Streaming
Recording：Press to start and stop recording, recording will light up,
stopping will turn off the light
