PTZ Camera Controller
PKC4000
15
Note: ① The search function is only available when the camera and controller are connected via LAN
cable. When they connected via RS232/422/485 port, please manually add the camera through the
"ADD" menu. ② The auto search function only searches for cameras with VISCA-IP port number 52381.
If the camera cannot be searched, please confirm and change the camera’s default port to 52381, or you
can manually add the camera through the "ADD" menu.
4.3.2 Manually Add Camera
Press the "ADD" button to enter camera add menu, first select the camera group, camera number and
the protocol you want to connect to.
The setting page for each protocol will be different, please select according to the table below.
After the setting is completed, touch “CALL” button to wake up the camera and save the setting.
There settings can be changed on the “ADD” page: Group, Cam number, Model, Camera Name,
PROTO, IP, Port, User, PWD, Addr, Uart, BaudR. The details are as follows:
General
options
Group
Camera group, optional: 1~10. Each group can add 10 cameras.
After saving, press the GROUP button and then press the number
button below to call the corresponding camera group.
Cam
Camera number, optional: 1~10.
After saving, press the CAM button to switch to the camera call state.
At this time, press the camera number button below to quickly call the
corresponding camera in the camera group.
Model
Used for compatibility with different brands of cameras, default is
Mode 1. Usually no need to change.
Name
Camera name. It can be modified via the Multi-function Digital Panel.
PROTO
Control protocol. NDI, VISCA-IP, ONVIF and VISCA-SONY protocols
can be selected for LAN connection; VISCA, PELCO-D and PELCO-P
protocols can be selected for RS232/422/485 connection.
