3
AN-16/i v.2 iNput Module user Guide
Package Contents
The AN-16/i v.2 Input Module box includes:
• AN-16/i v.2 Input Module
• DC Power supply for the AN-16/i v.2
• Documentation
Options for your system include:
• Cat-5e/Cat-6 UTP interconnect cables
• SB4 System Bridge
• Aviom Personal Mixer products such as the A360 Personal Mixer, A320 Personal Mixer,
A-16II Personal Mixer, or A-16R Rack-mount Personal Mixer for creating a monitoring
system
• Pro16 output devices such as the AN-16/o v.4 Output Module or AV-P2 Output Module
• D800, D800-Dante, D400, D400-Dante, A-16D and/or A-16D Pro A-Net Distributors
Also included with the system is a Warranty Registration, found within this User Guide. Be sure to fill out the
form and return it to Aviom, Inc. via mail or fax as soon as possible. Warranty info may also be submitted
on the Aviom website, www.Aviom.com.
About A-Net
A-Net® is a proprietary high-speed data transmission protocol developed by Aviom, capable of sending
and receiving high-quality digital audio using readily available Cat-5 cables.
A-Net is based on the physical layer of Ethernet, a Local Area Network (or LAN) technology. This provides
A-Net with a mature and robust base on which to build. However, it is important to note that A-Net devices
are not compatible with Ethernet devices.
Some of the benefits of using A-Net to transmit digital audio are:
• Virtually no latency; analog in to analog out is always less than one millisecond
• No ground loops
• Easy cabling using readily available components
• An unlimited number of A-Net devices can be used in a system
• Ease in spanning long distances between system components
There are two versions of Pro16 A-Net: the original Pro16 A-Net signal carries sixteen channels of digital
data while the enhanced Pro16e® version of A-Net is capable of carrying up to 64 channels of digital audio
data. Like standard Pro16 A-Net, Pro16e is a point-to-point digital audio protocol.
Pro16e A-Net data is intended for use with the A320 and A360 Personal Mixers which can take advantage
of the higher network channel count that Pro16e provides.
