User Manual
Commercial Countertop Griddles, Charbroilers, and Ranges
5
www.AvantcoEquipment.com
Clearances
The appliance area must be kept free and clear of all combustibles.
MODEL
COMBUSTIBLE NON-COMBUSTIBLE
REAR SIDES REAR SIDES
Countertop Thermostatic Gas Griddles 8" 6” 0” 0”
Countertop Manual Gas Griddles 8" 6” 0” 0”
Countertop Radiant Gas Charbroilers 8" 6” 0” 0”
Countertop Gas Hot Plates 8" 6” 0” 0”
Rating Plate
Information on this plate includes the model, serial number, BTU/hour input of the burners,
operating gas pressure in inches WC, and whether the appliance is orificed for natural or
propane gas. When communicating with factory about a unit or requesting special parts or
information, rating plate data is essential for proper identification.
Recommendations Before Installation
Before installing the gas supply system, observe the pipes and fittings, check the components
for dirt, clean internally with compressed air to eliminate possible particles, and prevent burners
and valves from becoming clogged.
After cleaning, use thread sealant to connect the equipment to the gas network. For correct
application, avoid concentrating the compound on the first two threads of the pipe, otherwise it
may generate particles that will clog the system injectors.
!
IMPORTANT
FAILURE TO INSTALL THE PRESSURE REGULATOR WILL VOID YOUR WARRANTY.
Gas Standards & Codes
Installation of this appliance must be in accordance with local installation codes, including:
1. The appliance and its individual shuto valve must be disconnected from the gas supply
piping system during any system pressure testing when this teste pressure exceeds 1/2 PSI
(3.45 kPa).
2. The appliance shall be isolated from the gas supply piping system by closing the manual
shut-o valve during any pressure test of the gas supply piping system at test pressures
equal to or less than 1/2 PSI (3.45 kPa).
