User Manual
Commercial Countertop Griddles, Charbroilers, and Ranges
25
www.AvantcoEquipment.com
User Manual
22 www.AvantcoEquipment.com
PARTS LIST
COUNTERTOP GAS GRIDDLE, THERMOSTATIC
#
PART QUANTITY BY MODEL (SIZE)
PART # DESCRIPTION 15" 24" 36" 48" 60"
1
8.09.03.00000400 LEG ASSEMBLY 4 4 4 4 6
2
8.01.53.00002000 GAS VALVE ASSEMBLY 1 2 3 4 5
3
8.01.53.00001900 KNOB ASSEMBLY 1 2 3 4 5
4
8.01.53.00000060 KNOB BEZEL 1 2 3 4 5
5
--- GREASE TRAP 1 1 1 1 2
6
8.01.53.00000045 FRONT PANEL 1 1 1 1 1
7
8.01.53.00002300 GAS DISTRIBUTION TUBE ASSEMBLY 1 1 1 1 1
8
8.20.55.42425362 STAINLESS STEEL FLEX TUBE 3/16" 1 2 3 4 5
9
--- THERMOCOUPLE 1 2 3 4 5
10
--- PILOT 1 2 3 4 5
11
8.01.53.00002600 INTERNAL FRAME ASSEMBLY 1 1 1 1 1
12
8.01.52.00000788 EXTERNAL SIDE PANEL 2 2 2 2 2
13
8.01.53.00000046 ORIFICE ASSEMBLY SUPPORT BRACKET 1 2 3 4 5
14
8.01.52.00000785 BURNER DEFLECTOR 1 2 3 4 5
15
8.01.53.00002100 BURNER ASSEMBLY 1 2 3 4 5
16
8.01.53.00002500 GRIDDLE PLATE ASSEMBLY 1 1 1 1 1
17
8.01.52.00000632 GAS TUBE BACK BRACKET 1 1 1 1 1
18
8.01.52.00000786 EXTERNAL BACK PANEL 1 1 1 1 1
19
8.01.52.00000787 INTERNAL BACK PANEL 1 1 1 1 1
GREASE TRAP CODES
Model 15" 8.01.53.00000078
Model 24" 8.01.52.00000781
Model 36" 8.01.53.00000080
Model 48" 8.01.53.00000094
Model 60" 8.01.52.00000781 and 8.01.53.00000080
8.01.53.00000075
User Manual
24 www.AvantcoEquipment.com
PARTS LIST
COUNTERTOP GAS GRIDDLE, MANUAL
#
PART QUANTITY BY MODEL (SIZE)
PART # DESCRIPTION 15" 24" 36" 48" 60"
1
8.01.53.00009500 BURNER ASSEMBLY 1 2 3 4 5
2
8.01.52.00072100 GRIDDLE PLATE ASSEMBLY 1 1 1 1 1
3
8.01.52.00000785 BURNER DEFLECTOR 1 2 3 4 4
4
8.01.53.00000042 GAS TUBE BACK BRACKET 1 1 1 1 1
5
8.01.52.00000786 EXTERNAL BACK PANEL 1 1 1 1 1
6
8.01.52.00000787 INTERNAL BACK PANEL 1 1 1 1 1
7
--- STAINLESS STEEL 4.5 X 10 NT OPEN RPX RIVET 3 7 11 13 10
8
--- STAINLESS STEEL SCREW 4.2 X 13 NT 27 32 35 35 45
9
8.01.52.00000788 EXTERNAL SIDE PANEL 2 2 2 2 2
10
8.09.03.00000400 LEG ASSEMBLY 4 4 4 4 6
11
--- RED FS UNC 1.4-2OF X 1.2 ZB SCREW 2 2 2 2 2
12
--- INTERNAL FRAME ASSEMBLY 1 1 1 1 1
13
8.01.52.00072600 GAS DISTRIBUTION TUBE ASSEMBLY 1 1 1 1 1
14
8.01.52.00000780 FRONT PANEL 1 1 1 1 1
15
8.01.53.00001900 KNOB ASSEMBLY 1 2 3 4 5
16
8.01.52.00000781 GREASE TRAP 1 1 1 1 2
17
8.01.52.00072500 PILOT TUBE ASSEMBLY -- 1 1 2 2
18
--- THREDEAD RIVET 2 2 2 2 2
User Manual
24 www.AvantcoEquipment.com
PARTS LIST
COUNTERTOP GAS GRIDDLE, MANUAL
#
PART QUANTITY BY MODEL (SIZE)
PART # DESCRIPTION 15" 24" 36" 48" 60"
1
8.01.53.00009500 BURNER ASSEMBLY 1 2 3 4 5
2
8.01.52.00072100 GRIDDLE PLATE ASSEMBLY 1 1 1 1 1
3
8.01.52.00000785 BURNER DEFLECTOR 1 2 3 4 4
4
8.01.53.00000042 GAS TUBE BACK BRACKET 1 1 1 1 1
5
8.01.52.00000786 EXTERNAL BACK PANEL 1 1 1 1 1
6
8.01.52.00000787 INTERNAL BACK PANEL 1 1 1 1 1
7
--- STAINLESS STEEL 4.5 X 10 NT OPEN RPX RIVET 3 7 11 13 10
8
--- STAINLESS STEEL SCREW 4.2 X 13 NT 27 32 35 35 45
9
8.01.52.00000788 EXTERNAL SIDE PANEL 2 2 2 2 2
10
8.09.03.00000400 LEG ASSEMBLY 4 4 4 4 6
11
--- RED FS UNC 1.4-2OF X 1.2 ZB SCREW 2 2 2 2 2
12
--- INTERNAL FRAME ASSEMBLY 1 1 1 1 1
13
8.01.52.00072600 GAS DISTRIBUTION TUBE ASSEMBLY 1 1 1 1 1
14
8.01.52.00000780 FRONT PANEL 1 1 1 1 1
15
8.01.53.00001900 KNOB ASSEMBLY 1 2 3 4 5
16
8.01.52.00000781 GREASE TRAP 1 1 1 1 2
17
8.01.52.00072500 PILOT TUBE ASSEMBLY -- 1 1 2 2
18
--- THREDEAD RIVET 2 2 2 2 2
Parts List
COUNTEROP GAS GRIDDLE, MANUAL
