User Manual
Commercial Countertop Griddles, Charbroilers, and Ranges
22
www.AvantcoEquipment.com
User Manual
22 www.AvantcoEquipment.com
PARTS LIST
COUNTERTOP GAS GRIDDLE, THERMOSTATIC
#
PART QUANTITY BY MODEL (SIZE)
PART # DESCRIPTION 15" 24" 36" 48" 60"
1
8.09.03.00000400 LEG ASSEMBLY 4 4 4 4 6
2
8.01.53.00002000 GAS VALVE ASSEMBLY 1 2 3 4 5
3
8.01.53.00001900 KNOB ASSEMBLY 1 2 3 4 5
4
8.01.53.00000060 KNOB BEZEL 1 2 3 4 5
5
--- GREASE TRAP 1 1 1 1 2
6
8.01.53.00000045 FRONT PANEL 1 1 1 1 1
7
8.01.53.00002300 GAS DISTRIBUTION TUBE ASSEMBLY 1 1 1 1 1
8
8.20.55.42425362 STAINLESS STEEL FLEX TUBE 3/16" 1 2 3 4 5
9
--- THERMOCOUPLE 1 2 3 4 5
10
--- PILOT 1 2 3 4 5
11
8.01.53.00002600 INTERNAL FRAME ASSEMBLY 1 1 1 1 1
12
8.01.52.00000788 EXTERNAL SIDE PANEL 2 2 2 2 2
13
8.01.53.00000046 ORIFICE ASSEMBLY SUPPORT BRACKET 1 2 3 4 5
14
8.01.52.00000785 BURNER DEFLECTOR 1 2 3 4 5
15
8.01.53.00002100 BURNER ASSEMBLY 1 2 3 4 5
16
8.01.53.00002500 GRIDDLE PLATE ASSEMBLY 1 1 1 1 1
17
8.01.52.00000632 GAS TUBE BACK BRACKET 1 1 1 1 1
18
8.01.52.00000786 EXTERNAL BACK PANEL 1 1 1 1 1
19
8.01.52.00000787 INTERNAL BACK PANEL 1 1 1 1 1
GREASE TRAP CODES
Model 15" 8.01.53.00000078
Model 24" 8.01.52.00000781
Model 36" 8.01.53.00000080
Model 48" 8.01.53.00000094
Model 60" 8.01.52.00000781 and 8.01.53.00000080
8.01.53.00000075
Parts List
COUNTEROP GAS GRIDDLE, THERMOSTATIC
