User Manual
Commercial Countertop Griddles, Charbroilers, and Ranges
12
www.AvantcoEquipment.com
LGP Gas Installation at Low Pressure
To use the product with LPG gas at low pressure, it is necessary that the product is checked with
the injector for use of LPG gas, if it is not with the appropriate injector, the gas conversion should
be performed following the steps described in item 2.5 of this manual.
The installation of low pressure LPG gas must be carried out in a gas station distant from the
equipment used.
A first stage (first) regulating valve with an inlet of 7 kgf/cm2 and an outlet pressure of 1.2 kgf/cm2
is installed on site, placing copper or carbon steel piping as a gas conductor to the equipment
seamless. Install at the end, next to the equipment a second 2° (second) stage valve with inlet
pressure of 1.2 kgf /cm2 and outlet pressure of 2.8 kPa or 280mmc.a.H2O.
Using a certified hose, connect the valve directly to the pressure regulator at the gas inlet at
the rear of the product, securing both ends with clamps to both the 2nd stage valve and the
equipment.
Note: If in doubt consult the legislation in force in your state/ municipality.
Gas Leak Check
Before lighting the equipment and putting it into operation, check all gaskets on the gas supply
line for leaks. For this, do not use any type of wrench to check for leaks, use a sudsy soap and
water solution.
Follow the steps below for the correct procedure to power on:
1. Turn pilot valves to OFF position by turning adjusting screws clockwise.
2. Turn on the manual gas valve on the inlet side of the gas supply line.
3. Check for gas leaks at the flexible coupling or gas connector connection using a soap
solution.
4. In moderation, spray or scrub the solution with soap on gas connections - active bubbling
indicates the location of the gas leak.
5. If a gas leak is detected, turn o the manual gas valve at the inlet side of the gas line. Call
your certified and licensed service technician.
6. If the equipment has no gas leak, continue with the equipment operating instruction.
!
IMPORTANT
