9
Clearance Requirements
When installing the refrigerator under a counter, follow the recommended spacing dimensions shown.
To ensure proper service access and venlaon, allow at least 1-2” of clearance at the back,
1
/
4
” at the top, and
1
/
4
” at the sides. If the door side is against a wall, allow at least 2
3
/
8
” of clearance. The installaon should allow
the unit to be pulled forward for servicing, if necessary.
90
Door Swing
1 /
16
“
24
3
/
4
"
2 /”
1-2”
1/4
”
1/4”
Note: The refrigerator should be installed on a rm and level surface that will be able to support
the enre weight of a fully loaded unit. It is important for the refrigerator to be level in order to
work properly. If needed, you can adjust the height of the refrigerator by rotang the feet. See the
“Leveling the Refrigerator” secon.
Note: A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with
Naonal Electrical Code and local codes and ordinances, is required.
Notes:
• To ensure proper service access and venlaon, allow between 1 - 2 inches of clearance at
the back as shown in the diagram.
• The installaon should allow the unit to be pulled forward for servicing, if necessary.
• A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with
Naonal Electrical Code and local codes and ordinances, is required.
Top View: Side View:
